Deaf Bonce AP- M61AC PRO

Type: Midrange

Size: 6.5"

Frequency Response: 160 – 12,500 Hz

Package Quantity: Pair

Power Handling:

RMS Power: 180 W

Max Power: 360 W

Build & Materials:

Voice Coil Size: 1.50"

Voice Coil Wire: Copper-Clad Aluminum (CCAW)

Cone Material: Pressed Paper

Surround Material: Cloth

Magnet Type: Ferrite

Frame: Aluminum

Performance Characteristics:

Impedance: 4 Ohm

Sensitivity (SPL): 101.9 dB

Resonance Frequency (Fs): 158 Hz

Total Q Factor (Qts): 0.41

BL (Magnetic Force): 8.40

Vas (Equivalent Air Volume): 4.50 L

Mounting Dimensions:

Mounting Depth: 75.0 mm

Cut-Out Diameter: 156.0 mm

Shipping Weight:

Gross Weight: 11.7 Ibs
